The Caledonia-5 is the bike we keep reaching for when we know the odometer’s going well past the triple-digit mark. Long rides invariably have some smooth tarmac, some junk pavement over backroads, a cutty singletrack connector, and maybe even your own local Strade Bianche sector. So we built a bike that could take on all of them, do it well, and fit fenders in case the ominous clouds turn into a downpour 130km into your day.
AERO CABLE MANAGEMENT
The Cervélo frame, fork, handlebars, and associated components are designed to hide brake and shift control lines (mechanical, electrical, and hydraulic) from the wind for improved aerodynamics, without sacrificing usability or performance.
PERFORMANCE FIT
The Caledonia-5's integrated stem and two bearing cap options allow for stacks ranging between an aggressive 7mm and a relaxed 22mm without the use of spacers. With a wider fit coordinate range (stack) of 580mm to 687mm, the Caledonia can be slammed or more upright. All while looking and being seamlessly fast in the wind.
REMOVABLE FDM
Our bolt-on front derailleur mount is made from high-strength aluminum alloy and attaches to the frame with two countersunk screws. This allows for easy replacement in the event of damage but also enables you to adapt to new standards as they become available or remove the front derailleur mount completely if you choose a 1x system.
INTEGRATED ACCESSORY MOUNTS
Integrated mounts enable the use of fenders, lights, and computers without compromising the aerodynamics or structure of your bike. The built-in mount systems provide a simple and clean-looking solution.
Frameset/Fork |
Cervelo All-Carbon Frameset with SP24 Carbon Seatpost, Tapered Caledonia-5 Carbon Fork, Cervelo ST32 Alloy Stem, HB13 Carbon Handlebar |
Groupset | Ultegra 12 spd, Crankset Shimano Ultegra 12s R8100, 52/36T, Cassette Shimano Ultegra 12s 11-34, Roto MT800 160mm(F) & 140mm(R) |
Wheels | Zipp 303s, 45mm rim depth, Center-Lock, Hookless, Tubeless Ready |
Tire | Vittoria Corsa NEXT TLR 700 x 28c |
48 | 51 | 54 | 56 | 58 | 61 | |
---|---|---|---|---|---|---|
Reach | mm | 360 | 369 | 378 | 387 | 396 | 405 |
Stack | mm | 505 | 530 | 555 | 580 | 605 | 630 |
Head Tube Angle | 70.5° | 71.5° | 72° | 72° | 72° | 72° |
Front Center | mm | 579.4 | 581.7 | 591.5 | 608.5 | 626 | 643 |
Bottom Bracket Drop | mm | 76.5 | 76.5 | 74 | 74 | 71.5 | 71.5 |
Head Tube Length | mm | 89.5 | 109.9 | 136 | 162.3 | 191.2 | 217.5 |
Top Tube Length | mm | 502 | 522 | 543 | 565 | 581 | 598 |
Seat Tube Angle | 74.5° | 74° | 73.5° | 73° | 73° | 73° |
Standover Height | mm | 712 | 752 | 784 | 807 | 834 | 857 |
Trail | mm | 60 | 60 | 60 | 60 | 60 | 60 |
Wheel Size | 700C | 700C | 700C | 700C | 700C | 700C |
Fork Offset | mm | 59 | 53 | 50 | 50 | 50 | 50 |
Wheelbase | mm | 982.2 | 984.5 | 995.2 | 1012.3 | 1030.7 | 1047.8 |
Chainstay Length | mm | 415 | 415 | 415 | 415 | 415 | 415 |
